TD307PAII/Awards
 |
5 Mice
MacUser, 26 October 2007
|
 |
5 Star
MacFormat, September 2007
|
 |
5 Star, PC & MP3 Speaker Systems Category
What HiFi? Sound and Vision, August 2007
|
|
|
TD307PAII/FEATURE
The next level of quality for music
Discover a higher level of music enjoyment just by connecting the TD307PAII system to any portable device, PC or TV. It's a level of quality that's appreciated by artists and recording engineers - one that got a 5-star Speaker Award from What Hi-Fi? magazine in 2007.
An ideal mini-system
The TD307PAII uses the same technology as other high-end Eclipse TD models to pack a surprisingly great performance into a speaker this size. Use it with the integrated amplifier to enjoy the full benefit of our Time Domain approach to precisely reproducing music.
Surprisingly better quality
The TD307PAII can connect to and improve any audio product, be it a digital-audio player, computer or even a mobile phone. This integrated amplifier also has a dedicated 2.1-channel output for a subwoofer option.
|
|
|
|
TD307PAII/SPEC
| Product Name | TD307II Speaker & Amplifier |
| Color | Silver,Black,White |
Specifications
TD307PAII
Amplifier | • Frequency Response | : 10Hz-100kHz (±3dB) |
| • Rated Output | : 12W (T,H,D, 1%) |
| • Harmonic Distortion | : 0.05% max (at 1kHz,1W output) |
| • Input | : Line (stereo) 1 |
| : Line (stereo mini) 1 |
| • Input Impedance | : 10kΩ |
| • Input Sensitivity | : 180mVrms (at 12W output) |
| • Load Impedance | : 8Ω |
| • Cut-off Frequency | : 90Hz (-3dB) |
| • Output | : Line (stereo mini) 1 |
| • Power Consumption | : 18W |
| Maximum Dimensions | Amp W159 x H154 x D137 (mm) |
| AC Adapter W121 x H33 x D56 (mm) |
| Weight | Amp 930g , AC Adapter 360g |
| Accessories | speaker code | (3.0m) x 2 |
| stereo mini <- -> stereo mini | (1.6m) x 1 |
| stereo mini <- -> RCA code | (1.6m) x 1 |
| security wire for fall prevention | x 2 |
|
|
TD307PAII/PRODUCT BROCHURES, MANUALS
|
|
|
